Mezzanine Structural Engineer Stamped Drawings

At ASI, we include a complimentary conceptual CAD drawing with your quote to give you a general idea of what a used mezzanine will look like in your warehouse. However, the final product may vary slightly from the initial concept in terms of truss spacing, column size, and other inventory-dependent factors.

An engineer stamped drawing will include any such changes that were made to the initial design.

What Is An Engineer Stamped Drawing?

Structural engineer stamped drawings give you a more detailed breakdown of your mezzanine work platform so you know exactly what you're getting.

ASI's CAD specialist sends a preliminary drawing to a certified engineering company for review. They will test to confirm the mezzanine's PSF rating, as well as make any recommendations for changes they see fit such as moving a column.

Finalized stamped drawings include specifications for every component of your used mezzanine work platform, from the smallest bolt to the largest support. In addition, the engineering details include an accurate weight capacity, which is especially helpful if you intend to install a heavy piece of equipment on top of your mezzanine.

The average cost for an engineer stamped mezzanine drawing from ASI is between $1,500 and $2,500 -- depending on the complexity. To request more information on mezzanine structural engineer stamped drawings call American Surplus today at (800) 876-3736.
