Don't Miss Out: Used BestReach Truck Loader Available Now!
Don't Miss Out: Used BestReach Truck Loader Available Now!
January 29, 2025
ASI has recently discovered a BestReach Truck Loader available in Greensboro, NC that would be perfect for your facility! This 80' truck loader features a blazing fast top belt speed of 200 fpm,
Don't Miss This Great Condition BestReach Truck Loader Available Now!
ASI has recently discovered a BestReach Truck Loader available in Greensboro, NC that would be perfect for your facility! This 80' truck loader features a blazing fast top belt speed of 200 fpm, with simple controls for streamlined automation of your truck loading operations. We're sure this material will move fast, so now is your chance to request a quote and pre-order the material you need before anyone else has the chance!
Request A Quote Here or call our Sales Office today at (800) 876-3736 to unlock industry leading 40 % savings on the warehouse storage equipment you need!
| Detailed Specifications |
| FOB | Greensboro, North Carolina |
| Model | BestReach 25/80-24 |
| Length Fully Extended | 80' 3" |
| Length Fully Retracted | 25' 3" |
| Extension | 55' |
| Overall Height | 38.5" |
| Conveyor Width | 41" |
| Overall Width | 68" |
| Belt Width | 24" |
| Belt Type | 2-Ply PVC |
| Belt Speed | 140-200FPM (preset to 200FPM) |
| Belt Direction | Load |
| Belt Drive | 5HP Chain Driven Drum Motor |
| Telescopic Movement | 1HP Gear Motor w/ dual synchronized chains |
| Telescopic Speed | 45 FPM |
| Power Supply | 3 Phase 480V |
| Control Voltage | 120V |
| Control Current | 8A |
| Load Capacity | 50 lbs./ft |
| Color | FMH Gray |
| Approximate Weight | 12,000 lbs. |
| Traverse Speed | 25 FPM |
| Traverse Power | 1 HP |
| Front Extended Downward Force | 25,000 lbs. |
| Front Retracted Downward Force | 7,000 lbs. |
| Rear Extended Downward Force | 10,000 lbs. |
| Rear Retracted Downward Force | 6,000 lbs. |
